Product information
Upgrade your system with the AMD A520 Ultra Durable Motherboard, featuring GbE LAN for reliable networking and bandwidth management. Ideal for stable and efficient connectivity.
Equipped with PCIe 3.0 x4 M.2 support, this motherboard ensures fast data transfer and expansion capabilities. Perfect for adding high-speed storage solutions.
Featuring Smart Fan 5 technology, the A520 motherboard provides advanced cooling options to maintain optimal performance. Enjoy a quieter and cooler system environment.
With anti-sulfur resistors, this motherboard is designed for enhanced durability and longevity. A great choice for users seeking a reliable and high-quality motherboard solution.
Model
A520M K V2
Supported Memory
DDR4
Onboard Graphics
Integrated Graphics Processor with AMD Radeon™ Graphics support
Supported Audio
Realtek® ALC897 codec, 7.1-channel High Definition Audio
LAN
Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Wireless Communication module
None
Expansion slots
1 x PCIe 4.0 x16, 1 x PCIe 3.0 x16
Storage Interface
1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs
Supported USB
1 x USB 3.2 Gen 2 Type-C, 4 x USB 3.2 Gen 1 Type-A, 2 x USB 2.0
Internal I/O connectors
1x 24-pin ATX, 1x 8-pin CPU, 1x 4-pin CPU, 6x SATA, 2x USB 2.0, 1x USB 3.2 Gen 1
H/W monitoring
CPU temperature, Fan speed,Voltage detection,Temperature detection,Water cooling flow rate detection.
BIOS
1 x 128 Mbit flash,UEFI BIOS,
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
Support for APP Center,* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.,@BIOS,EasyTune.Smart Backup,System Information Viewer,Support for Q-Flash.
Operating System
Windows 10 64-bit, Windows 11 64-bit
Form Factor
Micro ATX
